Site ROM9
ROM9
ROMA (sede INGV), Roma
- Id: 269
- Spatial Reference System: GCS_WGS_1984
- Latitude [°]: 41.82869
- Longitude [°]: 12.51553
- Elevation [m]: 50
- StartTime: 01/03/2003 00:00:00
- EndTime:
- Type: PERMANENT
- Description: ROMA (sede INGV), Roma
- Site Name: ROM9
- Station Name: IV.ROM9
-
Sensors: KINEMETRICS EPISENSOR (m/s**2) - Q Final:
- Allegato:
- Note:
Map Layers
Housing
Geology
Preferred | Bibliography | Monography | Conceptual Model Value | |
---|---|---|---|---|
Yes | BONOMO R., D’AMBROGI C., D’OREFICE M., FIORENZA D., GAFÀ R. M. MONTI G.M., Di MANNA M., ROMA M., VITA L., Final Report Development of a conceptual geological model for five seismic station with accelerometer of the INGV Seismic Network, Internal Report ISPRA-INGV (2017) |
|
0 | |
No | Monti G. M., Martarelli L., Gafà R. M., Olivetta L., Caratterizzazione geolitologica dei siti su cui ricadono le stazioni della Rete Sismica Nazionale dell’INGV, INGV- ISPRA 2016-17 Agreement (protocol INGV 2016/0003777 of 04/04/2016): "Scientific and technical collaboration aimed at the geolithological characterization of the sites of the stations of the national INGV seismic network "(Scientific Coordinators: P. Bordoni and G.M. Monti) (2016) |
|
5 |
Cartography | Geological Cross Section |
Latitude 1 [°] | Longitude 1 [°] | Latitude 2 [°] | Longitude 2 [°] | Spatial Ref Sys | |
---|---|---|---|---|---|---|---|
Foglio ROMA - Carta Geologica d’Italia 1:100,000 |
|
41.82466 | 12.51244 | 41.83377 | 12.51984 | GCS_WGS_1984 |
Seismology
Preferred | Start time | End time | Noise variability types | Frequency range min [Hz] | Frequency range max [Hz] | Band Instrument | Picture of rotated ratio | Picture of ratio | Number of peaks | |
---|---|---|---|---|---|---|---|---|---|---|
No | 10/03/2017 10:00:00 | 10/03/2017 12:00:00 | DAYTIME | 0.2 | 20 | EH |
|
|
1 | |
No | 09/03/2017 11:00:00 | 09/03/2017 13:00:00 | DAYTIME | 0.2 | 20 | EH |
|
|
1 | |
Yes | 19/08/2015 22:59:58 | 20/08/2015 22:59:59 | DAYTIME | 0.1 | 15 | HH |
|
|
0 |
Geophysics
Id | Type | Investigation | Pref. | Latitude [°] | Longitude [°] | Elevation [m] | Figure | Monography | |
---|---|---|---|---|---|---|---|---|---|
5 | NON_LINEAR_CURVE | RC | YES | 41.828419 | 12.51553 | 50 |
|
|
|
21 | VELOCITY_PROFILE | DH | NO | 41.828419 | 12.51553 | 50 |
|
|
|
3 | VELOCITY_PROFILE | SA | NO | 41.828419 | 12.51553 | 50 |
|
|
|
28 | VELOCITY_PROFILE | CH | NO | 41.828419 | 12.51553 | 50 |
|
|
|
53 | VELOCITY_PROFILE | COMPOUND | YES | 41.828419 | 12.51553 | 50 |
|
